• Otel Forjat – Calit si Temperat
• W.L.L. ( Sarcina Limita de Lucru) este pentru tragere in linie dreapta. Pentru ridicare in unghi, consultati pagina 180 din Catalogul General Crosby.
• Rezistenta la oboseala testata la 1-1/2 ori din Sarcina Limita de Lucru la 20.000 cicluri.
• Este conform sau depaseste toate cerintele ASME B30.26 inclusiv identificarea, ductilitatea, design factor, sarcina de proba si cerintele de temperatura. Important, aceste bolturi intalnesc alte cerinte de performante critice incluzand durata la oboseala, proprietatile de impact si trasabilitatea materialului, ne precizate in ASME B30.26.
• Recomandat pentru tragerea in linie.
• S – 279 cu filet METRIC.


DATE TEHNICE

• Forged Steel - Quenched & Tempered.
• Working Load Limits shown are for in-line pull. For angle loading, see page 180.
• Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles.
• Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements.
• Importantly, these bolts meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
• Recommended for in-line pull.
• S-279 threaded UNC.
• M-279 metric threaded.

** Sarcina maxima este de 5 ori mai mare decat Sarcina Limita de Lucru (W.L.L.) Sarcina Maxima de de Testare este de 2 ori Sarcina Limita de Lucru.

**La cerere: Filet special sau suruburi forjate pentru modificare de catre client
